What You'll Learn:

What AWS Direct Connect is and how BGP routing works
Why Transit VPC architecture is recommended for Direct Connect
How to configure Transit VPC using Terraform
Setting up Direct Connect Gateway and private virtual interfaces
VPC peering between main and transit VPCs
Deploying HAproxy router service for network routing

AWS Direct Connect allows you to establish dedicated network connections from your premises to Amazon VPC. This can reduce network costs, increase bandwidth throughput, and provide a more consistent network experience compared to internet-based VPN connections.

This beginner guide walks you through connecting your existing AWS infrastructure to a large private network using Direct Connect, managed entirely through Terraform as infrastructure as code.

Understanding the Problem

The challenge: your services within a VPC need to communicate with services in a separate private network. The network provider offers an AWS hosted connection as part of a signed contract to grant access via AWS Direct Connect.

Key questions to answer:

How do you integrate Direct Connect into an existing Terraform-managed infrastructure?
What are the best practices for routing configuration?
How do you handle IP range limitations from the network provider?

What is AWS Direct Connect?

AWS Direct Connect makes it easy to establish a dedicated network connection from your premises to Amazon VPC. A network provider has AWS facilities in a shared data center, allowing you to make a direct connection between your AWS network components and their network using physical hardware.

How Direct Connect Works

The basic implementation involves:

Configure Direct Connections

Create one or two Direct Connections in the AWS console, which automatically creates a Direct Connect Gateway.

Attach Private VIF

Attach a private Virtual Interface (VIF) to the gateway for each connection.

Exchange Routing Policies

Coordinate with provider network engineers to exchange BGP routing policies and configure allowed prefixes.

Critical Limitation: IP Range Restrictions

Important Discovery

AWS allocates private IPs in the 169.x.x.x range for BGP sessions and advertises the entire VPC CIDR block over BGP. Your advertised IP range is limited to a /30 maximum, and you cannot advertise individual subnets.

If your VPC CIDR is too large for the network provider to accept, you will need to create a separate VPC with a smaller CIDR block. This is where the Transit VPC pattern comes in.

The Transit VPC Solution

AWS recommends using a Transit VPC pattern for integrating Direct Connect connections. The Transit VPC acts as a bridge between your main VPC and the external network, using a unique IP range provided by your network provider.

Isolated CIDR

Use a smaller, provider-approved IP range that meets their routing policy requirements.

VPC Peering

Connect your main VPC to the Transit VPC using VPC peering for seamless communication.

Main VPC Terraform Configuration

First, define your main VPC using the Terraform AWS VPC module. This is the existing VPC you want to extend with Direct Connect access.

main-vpc.tf

variable "main_vpc_name" {
  description = "Name of your main VPC"
}

variable "main_vpc_cidr" {
  description = "CIDR of your main VPC, e.g. 10.1.0.0/16"
}

variable "private_app_subnet" {
  description = "Private subnet of your main VPC, e.g. 10.1.2.0/24"
}

variable "main_vpc_key_name" {
  default = "main-vpc-key"
  description = "Name of SSH key of your main VPC"
}

variable "aws_availability_zone" {
  description = "Your AWS AZ of your main VPC"
}

terraform {
  backend "s3" {
    bucket = "your-terraform-states-bucket"
    key    = "terraform.tfstate"
  }
}

module "vpc" {
  version  = "~> v2.0"
  source   = "terraform-aws-modules/vpc/aws"
  name     = var.main_vpc_name
  cidr     = var.main_vpc_cidr

  azs = [var.aws_availability_zone]
  private_subnets = [var.private_app_subnet]

  single_nat_gateway     = true
  one_nat_gateway_per_az = false
  enable_nat_gateway     = true
  enable_vpn_gateway     = false

  tags = {
    Terraform = "true"
  }
}

Export the necessary values from the main VPC module that will be used by the Transit VPC:

outputs.tf

output "main_vpc_id" {
  value = module.vpc.vpc_id
}

output "main_vpc_range" {
  value = module.vpc.vpc_cidr_block
}

output "main_vpc_az" {
  value = module.vpc.azs.0
}

output "main_vpc_key_name" {
  value = var.main_vpc_key_name
}

output "main_private_routing_table_id" {
  value = module.vpc.private_route_table_ids.0
}

output "main_public_routing_table_id" {
  value = module.vpc.public_route_table_ids.0
}

Transit VPC Terraform Configuration

Create a separate Terraform state for the Transit VPC. Import the outputs from the main VPC as remote state:

transit-vpc.tf (locals)

locals {
  main_private_routing_table = data.terraform_remote_state.main.outputs.main_private_routing_table_id
  main_public_routing_table  = data.terraform_remote_state.main.outputs.main_public_routing_table_id
  main_vpc_id                = data.terraform_remote_state.main.outputs.main_vpc_id
  main_vpc_range             = data.terraform_remote_state.main.outputs.main_vpc_range
  main_vpc_az                = data.terraform_remote_state.main.outputs.main_vpc_az
  main_vpc_key_name          = data.terraform_remote_state.main.outputs.main_vpc_key_name
}

Define the Transit VPC variables:

Variable	Description
transit_vpc_cidr	Your unique IP range in the network (e.g., 10.10.14.0/24)
transit_private_subnet	Private subnet for Transit VPC (e.g., 10.10.14.0/25)
transit_public_subnet	Public subnet for NAT gateway (e.g., 10.10.14.128/25)
network_dns_server	Primary DNS server IP from your network provider
network_dns_server_2	Secondary DNS server IP from your network provider

transit-vpc-module.tf

module "transit-vpc" {
  version  = "~> v2.0"
  source   = "terraform-aws-modules/vpc/aws"
  name     = var.transit_vpc_name
  cidr     = var.transit_vpc_cidr

  azs = [local.main_vpc_az]
  private_subnets = [var.transit_private_subnet]
  public_subnets  = [var.transit_public_subnet]

  single_nat_gateway     = true
  one_nat_gateway_per_az = false
  enable_nat_gateway     = true
  enable_vpn_gateway     = false

  enable_dhcp_options         = true
  dhcp_options_domain_name    = var.dhcp_options_domain_name
  dhcp_options_domain_name_servers = [
    var.network_dns_server,
    var.network_dns_server_2
  ]

  tags = {
    Terraform = "true"
  }
}

Direct Connect Terraform Configuration

Configure Direct Connect resources including the gateway and private virtual interfaces. These values are provided by your network provider:

Variable	Description
bgp_provider_asn	BGP autonomous system number of the provider
provider_vln_id	BGP VLAN ID from the provider
primary/secondary_bgp_key	BGP authentication keys for primary/secondary VIFs
primary/secondary_connection_id	Connection IDs from AWS console
primary/secondary_amazon_address	Amazon-side BGP IP addresses
primary/secondary_customer_address	Customer-side BGP IP addresses

direct-connect.tf

# Direct Connect Gateway
resource "aws_dx_gateway" "provider-gateway" {
  name            = "provider-dc-gateway"
  amazon_side_asn = "64512"  # Default value
}

# Associate gateway with Transit VPC VPN gateway
resource "aws_dx_gateway_association" "transit" {
  dx_gateway_id        = aws_dx_gateway.provider-gateway.id
  associated_gateway_id = aws_vpn_gateway.transit_vpn_gw.id
  allowed_prefixes     = [var.transit_vpc_cidr]
}

# Primary Virtual Interface
resource "aws_dx_private_virtual_interface" "primary" {
  connection_id    = var.primary_connection_id
  name             = "provider-vif-primary"
  vlan             = var.provider_vln_id
  address_family   = "ipv4"
  bgp_asn          = var.bgp_provider_asn
  amazon_address   = var.primary_amazon_address
  customer_address = var.primary_customer_address
  dx_gateway_id    = aws_dx_gateway.provider-gateway.id
  bgp_auth_key     = var.primary_bgp_key
}

# Secondary Virtual Interface (for redundancy)
resource "aws_dx_private_virtual_interface" "secondary" {
  connection_id    = var.secondary_connection_id
  name             = "provider-vif-secondary"
  vlan             = var.provider_vln_id
  address_family   = "ipv4"
  bgp_asn          = var.bgp_provider_asn
  amazon_address   = var.secondary_amazon_address
  customer_address = var.secondary_customer_address
  dx_gateway_id    = aws_dx_gateway.provider-gateway.id
  bgp_auth_key     = var.secondary_bgp_key
}

VPC Peering Configuration

Connect your main VPC to the Transit VPC using VPC peering. This allows services in both VPCs to communicate:

vpc-peering.tf

# Create VPC Peering Connection
resource "aws_vpc_peering_connection" "main-to-transit" {
  peer_vpc_id   = module.transit-vpc.vpc_id
  vpc_id        = local.main_vpc_id
  auto_accept   = true

  tags = {
    Name = "VPC Peering between main and transit VPC"
  }
}

# Route from main private subnet to transit VPC
resource "aws_route" "from-main-to-transit" {
  route_table_id            = local.main_private_routing_table
  destination_cidr_block    = var.transit_vpc_cidr
  vpc_peering_connection_id = aws_vpc_peering_connection.main-to-transit.id
}

# Route from main public subnet to transit VPC
resource "aws_route" "from-main-public-to-transit" {
  route_table_id            = local.main_public_routing_table
  destination_cidr_block    = var.transit_vpc_cidr
  vpc_peering_connection_id = aws_vpc_peering_connection.main-to-transit.id
}

# Route from transit VPC to main VPC
resource "aws_route" "from-transit-to-main" {
  route_table_id            = module.transit-vpc.private_route_table_ids.0
  destination_cidr_block    = local.main_vpc_range
  vpc_peering_connection_id = aws_vpc_peering_connection.main-to-transit.id
}

Security Group for Transit VPC

Configure the security group to allow HTTP traffic from the main VPC:

transit-security-group.tf

resource "aws_security_group" "transit_vpc_sg" {
  name        = "transit-vpc-sg"
  description = "Transit VPC SG"
  vpc_id      = module.transit-vpc.vpc_id

  ingress {
    description = "Allow HTTP from main VPC"
    from_port   = 80
    to_port     = 80
    protocol    = "tcp"
    cidr_blocks = [local.main_vpc_range]
  }

  ingress {
    description = "Allow SSH from main VPC"
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = [local.main_vpc_range]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }

  tags = { Name = "transit-vpc" }
}

Router Service with HAproxy

Deploy a router service using Docker and HAproxy within the Transit VPC to route traffic to the external network. This approach follows the open-closed principle, making it easy to extend without modifying existing services.

Create VPN Gateway

Attach a VPN gateway to the Transit VPC for OpenVPN access management.

Deploy EC2 Router Instance

Launch an EC2 instance with Docker installed, running HAproxy in a container.

Configure DNS Resolution

Add router private IP to hosts file on services that need to access the external network.

router-service.tf

# VPN Gateway for Transit VPC
resource "aws_vpn_gateway" "transit_vpn_gw" {
  tags = { Name = "transit-vpn-gw" }
}

resource "aws_vpn_gateway_attachment" "vpn_attachment" {
  vpc_id         = module.transit-vpc.vpc_id
  vpn_gateway_id = aws_vpn_gateway.transit_vpn_gw.id
}

resource "aws_vpn_gateway_route_propagation" "transit" {
  vpn_gateway_id = aws_vpn_gateway.transit_vpn_gw.id
  route_table_id = module.transit-vpc.private_route_table_ids.0
}

# Router Instance
resource "aws_instance" "router" {
  ami               = "ami-0eb89db7593b5d434"  # Ubuntu 20.04 LTS
  instance_type     = "t2.micro"
  availability_zone = local.main_vpc_az
  key_name          = local.main_vpc_key_name
  subnet_id         = module.transit-vpc.private_subnets.0
  private_ip        = var.router_private_ip

  vpc_security_group_ids = [aws_security_group.router_sg.id]

  user_data = file("router_init.sh")

  associate_public_ip_address = false
  tags = {
    Name    = "transit-vpc-router"
    Managed = "terraform"
  }
}

router_init.sh

#!/bin/bash
# Install Docker
apt-get update && apt-get install -y docker-ce

# Create HAproxy configuration
cat > /home/ubuntu/haproxy.cfg <<- "EOF"
global
    log stdout local0
    daemon
    maxconn 4000

defaults
    log               global
    mode              http
    option            httplog
    timeout connect   5s
    timeout check     5s
    timeout client    60s
    timeout server    60s

frontend http-in
    bind *:80
    acl domain1_acl hdr(host) -i domain-name-1.internal.com
    acl domain2_acl hdr(host) -i domain-name-2.internal.com
    use_backend domain1 if domain1_acl
    use_backend domain2 if domain2_acl

backend domain1
    mode http
    option forwardfor
    http-request replace-header Host .* domain-name-1.internal.com
    server domain1 domain-name-1.internal.com:443 ssl verify none

backend domain2
    mode http
    option forwardfor
    http-request replace-header Host .* domain-name-2.internal.com
    server domain2 domain-name-2.internal.com:443 ssl verify none
EOF

# Launch HAproxy container
docker run -d --restart always --name haproxy   --net=host -v /home/ubuntu:/usr/local/etc/haproxy:ro haproxy:2.1-alpine

Final Configuration Steps

After deploying the infrastructure, complete these final steps:

Configure OpenVPN Routing

Add both Transit VPC CIDR and main VPC CIDR to the OpenVPN server routing settings under VPN Settings.

Update Hosts File

Add the router private IP and domain names to the hosts file on instances in the main VPC that need external network access.

Test Connectivity

Start making HTTP requests to the external domain names and verify routing through the Transit VPC.

Frequently Asked Questions

What is the Transit VPC pattern in AWS?

Transit VPC is an AWS-recommended architecture where a separate VPC acts as a hub for connecting Direct Connect, VPN, and VPC peering connections. It isolates routing complexity from your main VPC.

Why can I only advertise a /30 CIDR over Direct Connect?

AWS allocates private IPs in the 169.x.x.x range for BGP sessions and advertises the VPC CIDR block. Network providers often have routing policy limits, requiring smaller CIDR blocks that is why Transit VPC with a unique provider-assigned range is necessary.

What is the difference between primary and secondary VIFs?

Primary and secondary virtual interfaces provide redundancy for Direct Connect. If the primary connection fails, BGP automatically fails over to the secondary connection, ensuring continuous network availability.

Why use HAproxy instead of migrating services to Transit VPC?

HAproxy routing follows the open-closed principle, allowing you to add new routes without modifying existing services. It also avoids the complexity of updating database connections, log storage, and other dependencies when migrating services.

How do I manage Terraform state for multiple VPCs?

Use separate Terraform workspaces or backends for each VPC. Use terraform_remote_state data source to import outputs from one state into another, enabling clean separation while maintaining necessary dependencies.

Need Help with AWS Infrastructure?

Our AWS experts can help you design and implement Direct Connect solutions and complex VPC architectures for your enterprise needs.

What You'll Learn:

What AWS Direct Connect is and how BGP routing works
Why Transit VPC architecture is recommended for Direct Connect
How to configure Transit VPC using Terraform
Setting up Direct Connect Gateway and private virtual interfaces
VPC peering between main and transit VPCs
Deploying HAproxy router service for network routing

This beginner guide walks you through connecting your existing AWS infrastructure to a large private network using Direct Connect, managed entirely through Terraform as infrastructure as code.

Understanding the Problem

Key questions to answer:

How do you integrate Direct Connect into an existing Terraform-managed infrastructure?
What are the best practices for routing configuration?
How do you handle IP range limitations from the network provider?

What is AWS Direct Connect?

How Direct Connect Works

The basic implementation involves:

Configure Direct Connections

Create one or two Direct Connections in the AWS console, which automatically creates a Direct Connect Gateway.

Attach Private VIF

Attach a private Virtual Interface (VIF) to the gateway for each connection.

Exchange Routing Policies

Coordinate with provider network engineers to exchange BGP routing policies and configure allowed prefixes.

Critical Limitation: IP Range Restrictions

Important Discovery

If your VPC CIDR is too large for the network provider to accept, you will need to create a separate VPC with a smaller CIDR block. This is where the Transit VPC pattern comes in.

The Transit VPC Solution

Isolated CIDR

Use a smaller, provider-approved IP range that meets their routing policy requirements.

VPC Peering

Connect your main VPC to the Transit VPC using VPC peering for seamless communication.

Main VPC Terraform Configuration

First, define your main VPC using the Terraform AWS VPC module. This is the existing VPC you want to extend with Direct Connect access.

main-vpc.tf

variable "main_vpc_name" {
  description = "Name of your main VPC"
}

variable "main_vpc_cidr" {
  description = "CIDR of your main VPC, e.g. 10.1.0.0/16"
}

variable "private_app_subnet" {
  description = "Private subnet of your main VPC, e.g. 10.1.2.0/24"
}

variable "main_vpc_key_name" {
  default = "main-vpc-key"
  description = "Name of SSH key of your main VPC"
}

variable "aws_availability_zone" {
  description = "Your AWS AZ of your main VPC"
}

terraform {
  backend "s3" {
    bucket = "your-terraform-states-bucket"
    key    = "terraform.tfstate"
  }
}

module "vpc" {
  version  = "~> v2.0"
  source   = "terraform-aws-modules/vpc/aws"
  name     = var.main_vpc_name
  cidr     = var.main_vpc_cidr

  azs = [var.aws_availability_zone]
  private_subnets = [var.private_app_subnet]

  single_nat_gateway     = true
  one_nat_gateway_per_az = false
  enable_nat_gateway     = true
  enable_vpn_gateway     = false

  tags = {
    Terraform = "true"
  }
}

Export the necessary values from the main VPC module that will be used by the Transit VPC:

outputs.tf

output "main_vpc_id" {
  value = module.vpc.vpc_id
}

output "main_vpc_range" {
  value = module.vpc.vpc_cidr_block
}

output "main_vpc_az" {
  value = module.vpc.azs.0
}

output "main_vpc_key_name" {
  value = var.main_vpc_key_name
}

output "main_private_routing_table_id" {
  value = module.vpc.private_route_table_ids.0
}

output "main_public_routing_table_id" {
  value = module.vpc.public_route_table_ids.0
}

Transit VPC Terraform Configuration

Create a separate Terraform state for the Transit VPC. Import the outputs from the main VPC as remote state:

transit-vpc.tf (locals)

locals {
  main_private_routing_table = data.terraform_remote_state.main.outputs.main_private_routing_table_id
  main_public_routing_table  = data.terraform_remote_state.main.outputs.main_public_routing_table_id
  main_vpc_id                = data.terraform_remote_state.main.outputs.main_vpc_id
  main_vpc_range             = data.terraform_remote_state.main.outputs.main_vpc_range
  main_vpc_az                = data.terraform_remote_state.main.outputs.main_vpc_az
  main_vpc_key_name          = data.terraform_remote_state.main.outputs.main_vpc_key_name
}

Define the Transit VPC variables:

Variable	Description
transit_vpc_cidr	Your unique IP range in the network (e.g., 10.10.14.0/24)
transit_private_subnet	Private subnet for Transit VPC (e.g., 10.10.14.0/25)
transit_public_subnet	Public subnet for NAT gateway (e.g., 10.10.14.128/25)
network_dns_server	Primary DNS server IP from your network provider
network_dns_server_2	Secondary DNS server IP from your network provider

transit-vpc-module.tf

module "transit-vpc" {
  version  = "~> v2.0"
  source   = "terraform-aws-modules/vpc/aws"
  name     = var.transit_vpc_name
  cidr     = var.transit_vpc_cidr

  azs = [local.main_vpc_az]
  private_subnets = [var.transit_private_subnet]
  public_subnets  = [var.transit_public_subnet]

  single_nat_gateway     = true
  one_nat_gateway_per_az = false
  enable_nat_gateway     = true
  enable_vpn_gateway     = false

  enable_dhcp_options         = true
  dhcp_options_domain_name    = var.dhcp_options_domain_name
  dhcp_options_domain_name_servers = [
    var.network_dns_server,
    var.network_dns_server_2
  ]

  tags = {
    Terraform = "true"
  }
}

Direct Connect Terraform Configuration

Configure Direct Connect resources including the gateway and private virtual interfaces. These values are provided by your network provider:

Variable	Description
bgp_provider_asn	BGP autonomous system number of the provider
provider_vln_id	BGP VLAN ID from the provider
primary/secondary_bgp_key	BGP authentication keys for primary/secondary VIFs
primary/secondary_connection_id	Connection IDs from AWS console
primary/secondary_amazon_address	Amazon-side BGP IP addresses
primary/secondary_customer_address	Customer-side BGP IP addresses

direct-connect.tf

# Direct Connect Gateway
resource "aws_dx_gateway" "provider-gateway" {
  name            = "provider-dc-gateway"
  amazon_side_asn = "64512"  # Default value
}

# Associate gateway with Transit VPC VPN gateway
resource "aws_dx_gateway_association" "transit" {
  dx_gateway_id        = aws_dx_gateway.provider-gateway.id
  associated_gateway_id = aws_vpn_gateway.transit_vpn_gw.id
  allowed_prefixes     = [var.transit_vpc_cidr]
}

# Primary Virtual Interface
resource "aws_dx_private_virtual_interface" "primary" {
  connection_id    = var.primary_connection_id
  name             = "provider-vif-primary"
  vlan             = var.provider_vln_id
  address_family   = "ipv4"
  bgp_asn          = var.bgp_provider_asn
  amazon_address   = var.primary_amazon_address
  customer_address = var.primary_customer_address
  dx_gateway_id    = aws_dx_gateway.provider-gateway.id
  bgp_auth_key     = var.primary_bgp_key
}

# Secondary Virtual Interface (for redundancy)
resource "aws_dx_private_virtual_interface" "secondary" {
  connection_id    = var.secondary_connection_id
  name             = "provider-vif-secondary"
  vlan             = var.provider_vln_id
  address_family   = "ipv4"
  bgp_asn          = var.bgp_provider_asn
  amazon_address   = var.secondary_amazon_address
  customer_address = var.secondary_customer_address
  dx_gateway_id    = aws_dx_gateway.provider-gateway.id
  bgp_auth_key     = var.secondary_bgp_key
}

VPC Peering Configuration

Connect your main VPC to the Transit VPC using VPC peering. This allows services in both VPCs to communicate:

vpc-peering.tf

# Create VPC Peering Connection
resource "aws_vpc_peering_connection" "main-to-transit" {
  peer_vpc_id   = module.transit-vpc.vpc_id
  vpc_id        = local.main_vpc_id
  auto_accept   = true

  tags = {
    Name = "VPC Peering between main and transit VPC"
  }
}

# Route from main private subnet to transit VPC
resource "aws_route" "from-main-to-transit" {
  route_table_id            = local.main_private_routing_table
  destination_cidr_block    = var.transit_vpc_cidr
  vpc_peering_connection_id = aws_vpc_peering_connection.main-to-transit.id
}

# Route from main public subnet to transit VPC
resource "aws_route" "from-main-public-to-transit" {
  route_table_id            = local.main_public_routing_table
  destination_cidr_block    = var.transit_vpc_cidr
  vpc_peering_connection_id = aws_vpc_peering_connection.main-to-transit.id
}

# Route from transit VPC to main VPC
resource "aws_route" "from-transit-to-main" {
  route_table_id            = module.transit-vpc.private_route_table_ids.0
  destination_cidr_block    = local.main_vpc_range
  vpc_peering_connection_id = aws_vpc_peering_connection.main-to-transit.id
}

Security Group for Transit VPC

Configure the security group to allow HTTP traffic from the main VPC:

transit-security-group.tf

resource "aws_security_group" "transit_vpc_sg" {
  name        = "transit-vpc-sg"
  description = "Transit VPC SG"
  vpc_id      = module.transit-vpc.vpc_id

  ingress {
    description = "Allow HTTP from main VPC"
    from_port   = 80
    to_port     = 80
    protocol    = "tcp"
    cidr_blocks = [local.main_vpc_range]
  }

  ingress {
    description = "Allow SSH from main VPC"
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = [local.main_vpc_range]
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }

  tags = { Name = "transit-vpc" }
}

Router Service with HAproxy

Create VPN Gateway

Attach a VPN gateway to the Transit VPC for OpenVPN access management.

Deploy EC2 Router Instance

Launch an EC2 instance with Docker installed, running HAproxy in a container.

Configure DNS Resolution

Add router private IP to hosts file on services that need to access the external network.

router-service.tf

# VPN Gateway for Transit VPC
resource "aws_vpn_gateway" "transit_vpn_gw" {
  tags = { Name = "transit-vpn-gw" }
}

resource "aws_vpn_gateway_attachment" "vpn_attachment" {
  vpc_id         = module.transit-vpc.vpc_id
  vpn_gateway_id = aws_vpn_gateway.transit_vpn_gw.id
}

resource "aws_vpn_gateway_route_propagation" "transit" {
  vpn_gateway_id = aws_vpn_gateway.transit_vpn_gw.id
  route_table_id = module.transit-vpc.private_route_table_ids.0
}

# Router Instance
resource "aws_instance" "router" {
  ami               = "ami-0eb89db7593b5d434"  # Ubuntu 20.04 LTS
  instance_type     = "t2.micro"
  availability_zone = local.main_vpc_az
  key_name          = local.main_vpc_key_name
  subnet_id         = module.transit-vpc.private_subnets.0
  private_ip        = var.router_private_ip

  vpc_security_group_ids = [aws_security_group.router_sg.id]

  user_data = file("router_init.sh")

  associate_public_ip_address = false
  tags = {
    Name    = "transit-vpc-router"
    Managed = "terraform"
  }
}

router_init.sh

#!/bin/bash
# Install Docker
apt-get update && apt-get install -y docker-ce

# Create HAproxy configuration
cat > /home/ubuntu/haproxy.cfg <<- "EOF"
global
    log stdout local0
    daemon
    maxconn 4000

defaults
    log               global
    mode              http
    option            httplog
    timeout connect   5s
    timeout check     5s
    timeout client    60s
    timeout server    60s

frontend http-in
    bind *:80
    acl domain1_acl hdr(host) -i domain-name-1.internal.com
    acl domain2_acl hdr(host) -i domain-name-2.internal.com
    use_backend domain1 if domain1_acl
    use_backend domain2 if domain2_acl

backend domain1
    mode http
    option forwardfor
    http-request replace-header Host .* domain-name-1.internal.com
    server domain1 domain-name-1.internal.com:443 ssl verify none

backend domain2
    mode http
    option forwardfor
    http-request replace-header Host .* domain-name-2.internal.com
    server domain2 domain-name-2.internal.com:443 ssl verify none
EOF

# Launch HAproxy container
docker run -d --restart always --name haproxy   --net=host -v /home/ubuntu:/usr/local/etc/haproxy:ro haproxy:2.1-alpine

Final Configuration Steps

After deploying the infrastructure, complete these final steps:

Configure OpenVPN Routing

Add both Transit VPC CIDR and main VPC CIDR to the OpenVPN server routing settings under VPN Settings.

Update Hosts File

Add the router private IP and domain names to the hosts file on instances in the main VPC that need external network access.

Test Connectivity

Start making HTTP requests to the external domain names and verify routing through the Transit VPC.

Frequently Asked Questions

What is the Transit VPC pattern in AWS?

Transit VPC is an AWS-recommended architecture where a separate VPC acts as a hub for connecting Direct Connect, VPN, and VPC peering connections. It isolates routing complexity from your main VPC.

Why can I only advertise a /30 CIDR over Direct Connect?

What is the difference between primary and secondary VIFs?

Why use HAproxy instead of migrating services to Transit VPC?

How do I manage Terraform state for multiple VPCs?

Need Help with AWS Infrastructure?

Our AWS experts can help you design and implement Direct Connect solutions and complex VPC architectures for your enterprise needs.

How to Extend AWS Infrastructure with Direct Connect: Terraform Guide

Understanding the Problem

What is AWS Direct Connect?

How Direct Connect Works

Configure Direct Connections

Attach Private VIF

Exchange Routing Policies

Critical Limitation: IP Range Restrictions

The Transit VPC Solution

Isolated CIDR

VPC Peering

Main VPC Terraform Configuration

Transit VPC Terraform Configuration

Direct Connect Terraform Configuration

VPC Peering Configuration

Security Group for Transit VPC

Router Service with HAproxy

Create VPN Gateway

Deploy EC2 Router Instance

Configure DNS Resolution

Final Configuration Steps

Configure OpenVPN Routing

Update Hosts File

Test Connectivity

Frequently Asked Questions

What is the Transit VPC pattern in AWS?

Why can I only advertise a /30 CIDR over Direct Connect?

What is the difference between primary and secondary VIFs?

Why use HAproxy instead of migrating services to Transit VPC?

How do I manage Terraform state for multiple VPCs?

Need Help with AWS Infrastructure?

How to Extend AWS Infrastructure with Direct Connect: Terraform Guide

Understanding the Problem

What is AWS Direct Connect?

How Direct Connect Works

Configure Direct Connections

Attach Private VIF

Exchange Routing Policies

Critical Limitation: IP Range Restrictions

The Transit VPC Solution

Isolated CIDR

VPC Peering

Main VPC Terraform Configuration

Transit VPC Terraform Configuration

Direct Connect Terraform Configuration

VPC Peering Configuration

Security Group for Transit VPC

Router Service with HAproxy

Create VPN Gateway

Deploy EC2 Router Instance

Configure DNS Resolution

Final Configuration Steps

Configure OpenVPN Routing

Update Hosts File

Test Connectivity

Frequently Asked Questions

What is the Transit VPC pattern in AWS?

Why can I only advertise a /30 CIDR over Direct Connect?

What is the difference between primary and secondary VIFs?

Why use HAproxy instead of migrating services to Transit VPC?

How do I manage Terraform state for multiple VPCs?

Need Help with AWS Infrastructure?
